Complete Set of Compact Schlenk Line: Double-Manifold with Size 15 O-Ring Joints, Cold Trap Assembly, Bubbler and Accessories
This COMPACT manifold fits well with smaller hood with limited space. It has four ports fitted with two 14/20 and two 24/40 inner joints. The distance between two adjacent ports is 100 mm (4 in), with total manifold length of 445 mm (17.5 in). The O.D of the two main tubes is 20 mm, with #15 O-ring joints at either end. This manifold functions as its full size version (cat. # 710202), yet comes with smaller form factor.Recipient :
* Required fields
or Cancel
740418
New
In Stock
Warning: Last items in stock!
Availability date: 01/01/2020
With 8mm hose connection on top and 14/20 standard taper outer joint at bottom.
With 10mm hose connection on top and 24/40 standard taper outer joint at bottom.
With 10 mm hose connection, overall height of 185 mm.
This compact manifold fits well with smaller hood with limited space. It has four ports fitted with two 14/20 and two 24/40 inner joints. The distance between two adjacent ports is 100 mm (4 in), with total manifold length of 445 mm (17.5 in). The O.D of the two main tubes is 20 mm, with #15 O-ring joints at either end. This manifold functions as its full...
This vacuum trap has standard taper joint size of 45/50, outer body with O.D. of 50mm and total length of 250mm.
To use with manifolds that have #15 O-ring joints
With 10mm O.D. serrated hose connection
With 12mm O.D. serrated hose connection
Plastic joint clip, easy to use with 14/20 joint size.
Plastic joint clip, easy to use with 19/22 joint size
Plastic joint clip, easy to use with 24/40 joint size
This COMPACT manifold fits well with smaller hood with limited space. It has four ports fitted with two 14/20 and two 24/40 inner joints. The distance between two adjacent ports is 100 mm (4 in), with total manifold length of 445 mm (17.5 in). The O.D of the two main tubes is 20 mm, with #15 O-ring joints at either end. This manifold functions as its full size version (cat. # 710202), yet comes with smaller form factor. Both front and rear main tubes are made of heavy wall borosilicate glass. All four ends of the manifolds have #15 O-ring joints, which are to connect with the cold trap assembly (Cat. # 711315), #15 O-ring hose adapters (713510) for nitrogen line/bubbler and #15 stopper (Cat. # 712150).
This complete set of Schlenk line includes:
(One) Compact Double-manifold with #15 O-ring Joints, two 14/20 ports and two 24/40 ports. Cat. # 710134.
(One) Vacuum Cold Trap Assembly with #15 O-ring Joints, Trap Body with 50 mm O.D. and 45/50 Standard Taper Joint. Cat. # 711315.
(One) Mineral Oil Bubbler with 26 mm O.D., Total Height of 180 mm. Cat. # 701026.
(Two) Hose Connection Adapter with 14/20 Outer Joint. Cat. # 123201.
(Two) Hose Connection Adapter with 24/40 Outer Joint. Cat. # 123202.
(Two) #15 O-ring Adapter to 10 mm Hose Connection. Cat. # 713510.
(One) #15 O-ring Adapter to 12 mm Hose Connection, for Vacuum Pump Connection with 1/2” Tubing. Cat. # 713516.
(One) #15 O-ring Stopper. Cat. # 712150.
(Five) Spherical 28/15 Stainless Steel Pinch Clamp. Cat. # 730028.
(Two) Standard Taper Joint Clips, 14/20. Cat. # 721014.
(Two) Standard Taper Joint Clips, 24/40. Cat. # 721024.
(Four) Standard taper joint clips, 19/22. Cat. # 721019.
